Applications: |
Market load, construction, parcel, tankers & 1616il /1 – exclusive drill rig vehicle available |
Engine: |
H Series 6 ETI3K turbocharged intercooled with inline FIP |
Power: |
160 hp @ 2400 rpm |
Torque: |
550 nm @ 1500-1700 rpm |
Clutch: |
Single plate dry plate, 14" dia 14.27 mm lining thick, axial clutch, F510 lining |
Transmission: |
ZF S636 OD gearbox; First Gear Ratio (FGR) 8.28:1 |
Suspension: |
Semi Elliptical multileaf |
Cabin: |
Factory built G45 cowl |
Tyre: |
10.00 x 20 - 16 PR nylon - ply (radial ply optional) |
Max speed: |
97 kmph |
Gradeability: |
25.73% |
GVW: |
16200 kgs |
Variants: |
1616 il
1616 il/1
1616 il/2
1616 il/3
|
Wheelbase: |
4330
4700
5334
6250 |
Loading span: |
18 ft
20 ft
24 ft
32 ft |
