| Applications: | Market load, construction, parcel, tankers & 1616il /1 – exclusive drill rig vehicle available |
|---|---|
| Engine: | H Series 6 ETI3K turbocharged intercooled with inline FIP |
| Power: | 160 hp @ 2400 rpm |
| Torque: | 550 nm @ 1500-1700 rpm |
| Clutch: | Single plate dry plate, 14" dia 14.27 mm lining thick, axial clutch, F510 lining |
| Transmission: | ZF S636 OD gearbox; First Gear Ratio (FGR) 8.28:1 |
| Suspension: | Semi Elliptical multileaf |
| Cabin: | Factory built G45 cowl |
| Tyre: | 10.00 x 20 - 16 PR nylon - ply (radial ply optional) |
| Max speed: | 97 kmph |
| Gradeability: | 25.73% |
| GVW: | 16200 kgs |
| Variants: | 1616 il 1616 il/1 1616 il/2 1616 il/3 |
| Wheelbase: | 4330 4700 5334 6250 |
| Loading span: | 18 ft 20 ft 24 ft 32 ft |
