| Applications: | Market load, construction, bulkers, minerals, tankers |
|---|---|
| Engine: | H Series 6 ETI3KI Turbocharged intercooled with inline FIP |
| Power: | 160 hp @ 2400 rpm |
| Torque: | 550 Nm @ 1500 - 1700 rpm |
| Clutch: | Single plate dry plate, with clutch booster, 380 mm facing dia |
| Transmission: | ZF S636 FGR 8.97:1 |
| Suspension: | Semi elliptical laminated multileaf |
| Cabin: | Factory built G45 Cowl |
| Tyre: | 10.00 x 20 - 16 PR Nylon - ply (radial ply optional) |
| Max speed: | 79 kmph |
| Gradeability: | 18.54% |
| GVW: | 25000 kgs |
| Wheelbase: | 4902 mm |
| Loading span: | 23.5 ft |
| Option: | Twin speed rear axle variant available |
