| Applications: | Road Construction, Earthwork, Aggregate, Sand |
|---|---|
| Engine: | H series - BS3 Turbocharged Intercooled |
| Power: | 180 HP @ 2400 rpm |
| Torque: | 660 Nm @ 1500-1700 rpm |
| Clutch: | Axial type 381 mm dia with ceramic discand actuated by clutch booster |
| Transmission: | 9 Speed GB FGR: 8.83 & Crawler : 12.73. |
| Suspension: | Semi-Elliptic Multi Leaf in front and Non - Reactive suspension at rear |
| Cabin: | G 45 Cowl / Cabin |
| Tyre: | 10.00 x 20 - 16 PR |
| Max speed: | 67 Kmph |
| Gradeability: | 41.7 % in CWG |
| GVW: | 25000 kgs |
| Wheelbase: | 3810 |
| Body Capacity: | 14 cu.m, 16 cu.m |
