| Applications: | Surface Transportation Blue Metal, Sand , Coal or other bulk Materials |
|---|---|
| Engine: | H series - BS3 Tubocharged intercooled |
| Power: | 180 HP @ 2400 rpm |
| Torque: | 660 Nm @ 1500-1700 rpm |
| Clutch: | Axial type 381 mm dia with ceramic disc and actuated by clutch booster |
| Transmission: | 9 Speed GB - FGR: 8.83 & Crawler : 12.73. |
| Suspension: | Semi-Elliptic Multi Leaf in front and Non - Reactive suspension at rear |
| Cabin: | G 45 Cowl / Cabin |
| Tyre: | 10.00 x 20 - 16 PR |
| Max speed: | 78 Kmph |
| Gradeability: | 29.7% in CWG |
| GVW: | 31000 kgs |
| Wheelbase: | 5250 |
| Body Capacity: | 8.5 cu.m |
