| Applications: | Coal - Surface & Rated load , Light dense bulk materials – Surface & Rated load |
|---|---|
| Engine: | 'H' Series BS3 Turbocharged Intercooled |
| Power: | 180HP @ 2400 RPM |
| Torque: | 670 N-m @ 1300-1600 RPM |
| Clutch: | 15" Diameter (381 mm) Hi-Dur ceramic clutch with clutch booster |
| Transmission: | 6 Speed GB - FGR - 8.51 |
| Suspension: | Front & Rear : Uprated semi-elliptic, multi-leaf Lift axle air suspended |
| Cabin: | 15" Diameter (381 mm) Hi-Dur ceramic clutch with clutch booster |
| Tyre: | 10R x 20-16 PR (Cross ply optional) |
| Max speed: | 76 Kmph |
| Gradeability: | 16.3% |
| GVW: | 16200 kgs |
| Wheelbase: | 6600 mm |
| Body Capacity: | 24cum Box |
| Gearbox: | Syncromesh 9 speed DD 8.83 FGR |
| Rear axle: | MT160 Capacity: 19000 Kg Ratio: 6.17:1 |
