| Applications: | Construction (sand, blue metal), Cement, Food grains, Market load |
|---|---|
| Engine: | H-series, 4-cylinder diesel engine with in-line fuel injection pump (FIP) |
| Power: | 120 HP @ 2400 RPM |
| Torque: | 415 Nm @1600 RPM |
| Clutch: | 310 mm diameter, single dry plate, push-type with hydraulic actuation and clutch booster |
| Transmission: | 6-speed overdrive gear box, FGR-6.93:1 |
| Suspension: | Parabolic leaf springs with shock absorbers |
| Cabin: | Day cabin with hydraulic tilt mechanism |
| Tyre: | 8.25 X 20-16 PR |
| Max speed: | 85 kmph |
| Gradeability: | 19.96% |
| GVW: | 12,900 kgs |
| Wheelbase: | 3400 | 3900 | 4500 | 4900 |
| Loading span: | 14 | 17 | 20 | 22 |
