| Applications: | Stone quarry, Marble , Granite ,Sand, Bricks, Road Construction | construction road construction, irrigation and canal projects, shallow mining and surface quarry |
|---|---|
| Engine: | 'H' Series BSIII Turbocharged Intercooled |
| Power: | 180HP @ – 2400 rpm |
| Torque: | 670 Nm @ 1300-1600 rpm |
| Clutch: | 15" Diameter (381 mm) Hi-Dur ceramic clutch with clutch boosters |
| Transmission: | 6 Speed GB - FGR - 8.51 |
| Suspension: | Front: semi-elliptic, multi-leaf with anti-roll bar and shock absorbers Rear: heavy-duty bogie suspension with V-rod |
| Tyre: | 10.00 X 20 – 16PR Nylon |
| Max speed: | 67 Kmph |
| Gradeability: | 42% |
| GVW: | 16200 kgs |
| Wheelbase: | 3900mm |
| Body Capacity: | 16 Cum box and 14 Cum box |
