| Applications: | Lime stone , Bauxite, Coal, Iron ore Mining Irrigation & canalprojects |
|---|---|
| Engine: | 'H' Series BS3 Turbocharged Intercooled |
| Power: | 225HP @ – 2500 rpm |
| Torque: | 800Nm @ 1400-1900 rpm |
| Clutch: | 15" Diameter (381 mm) Hi-Dur ceramic clutch with clutch boosters |
| Transmission: | 6 Speed GB - FGR - 8.51 |
| Suspension: | Front: semi-elliptic, multi-leaf with anti-roll bar and shock absorbers Rear: heavy-duty bogie suspension with V-rod |
| Tyre: | 11 x 20-16 PR (optional) : 11 x 20-18 PR with mine lug) |
| Max speed: | 72 Kmph |
| Gradeability: | 53% |
| GVW: | 16200 kgs |
| Wheelbase: | 3900mm |
| Body Capacity: | 16Cum box , 14 Rock |
