| Applications: | Construction, Roadwork, Earthwork & Light mining |
|---|---|
| Engine: | H series HA57L135 - BS3 turbocharged intercooled |
| Power: | 180 hp @ 2400 rpm |
| Torque: | 660 nm @ 1400-1800 rpm |
| Clutch: | Axial type 381 mm dia with organic lining and actuated by clutch booster |
| Transmission: | 6 speed GB - First Gear Ratio (FGR) - 8.5:1 |
| Suspension: | Semi Elliptical multi leaf and bogie suspension in rear |
| Cabin: | Factory built G91 day cab with sleeping provision |
| Tyre: | 10.00 x 20 - 16 PR nylon ply |
| Max speed: | 74 kmph |
| Gradeability: | 25% |
| GVW: | 25000 kgs |
| Wheelbase: | 3900 mm/4600 mm |
| Body Capacity: | 14 cum box & 14 cum scow (3600 mm WB) | 20 cum box (4600 mm WB) |
