| Applications: | Stone & Marble Quarry, Lime stone, Iron & ores, Canal & Irrigation |
|---|---|
| Engine: | H Series HA6ETI3U – BS3 Turbocharged Intercooled |
| Power: | 180 hp @ 2400 rpm |
| Torque: | 660 Nm @ 1500 - 1700 rpm |
| Clutch: | Axial type 381mm dia with organic lining and actuated by clutch booster |
| Transmission: | 9 speed 9S1110 GB - FIrst Gear Ratio (FGR) - 8.83:1, Crawler Gear Ratio (CGR) - 12.73:1 |
| Suspension: | Front: Semi eliptic multileaf, Rear : Bogie |
| Cabin: | Factory built G91 sleeper cab |
| Tyre: | 10.00 x 20 - 16 PR nylon; |
| Max speed: | 67kmph |
| Gradeability: | 42% |
| GVW: | 25000 kgs |
| Wheelbase: | 3900 mm |
| Body Capacity: | 14 & 16 cum box & 14 cum Rock |
