| Applications: | Overburden, Ores Stone & marbel quarries |
|---|---|
| Engine: | H Series HA57L165 CRS - BS3 turbocharged intercooled |
| Power: | 225 hp @ 2500 rpm |
| Torque: | 800 nm @ 1400 - 1900 rpm |
| Clutch: | Axial type 381 mm dia with organic lining and actuated by clutch booster |
| Transmission: | 9 speed 9S1110 GB - FIrst Gear Ratio (FGR) - 8.83:1, Crawler Gear Ratio (CGR) - 12.73:1 |
| Suspension: | Heavy duty bogie in rear |
| Cabin: | Factory built G91 day cab with sleeping provision |
| Tyre: | 11.00 x 20 - 16 PR nylon : option of 11.00 x 20 - 18 PR with mine lug pattern |
| Max speed: | 80 kmph |
| Gradeability: | 46% |
| GVW: | 25000 kgs |
| Wheelbase: | 3900 mm |
| Body Capacity: | 16 cum box | 14 cum rock & 14 cum rock with Hardox plates |
