| Applications: | Voluminous material movement at ports & Surface transportation |
|---|---|
| Engine: | H Series HA57L165 CRS - BS3 turbocharged intercooled |
| Power: | 225 hp @ 2500 rpm |
| Torque: | 800 nm @ 1400-1900 rpm |
| Clutch: | Axial type 381 mm dia with organic lining and actuated by clutch booster |
| Transmission: | 9 speed GB - First Gear Ratio (FGR) - 8.83:1, Crawler Gear Ratio (CGR) - 12.73:1 |
| Suspension: | Heavy duty bogie in rear. |
| Cabin: | Factory built G91 day cab with sleeping provision; a/c option |
| Tyre: | 11.00 x 20 - 16 PR nylon ply |
| Max speed: | 82 kmph |
| Gradeability: | 33% |
| GVW: | 31000 kgs |
| Wheelbase: | 5250 mm |
| Body Capacity: | 19 cum box | 22 cum box |
