Applications: |
Cement, Steel, ODC |
Engine: |
H Series CRS BS III |
Power: |
225 hp @ 2500 rpm |
Torque: |
800 nm @ 1400-1900 rpm |
Clutch: |
380 mm dia disc with organic lining actuated with clutch boosters |
Transmission: |
9 speed synchromesh GB (ZF9S1110); First Gear Ratio 8.83:1, Crawler Gear Ratio 12.73:1 |
Suspension: |
Front : Parabolic suspension Rear : Semi elliptic multileaf; bogie option |
Cabin: |
Factory built G91 sleeper cab |
Tyre: |
11.00 x 20 - 16 PR cross ply; radial tyres optional |
Max speed: |
80 kmph |
Gradeability: |
21% |
GVW: |
49000 kgs (with tri-axle trailer) |
Wheelbase: |
3900 mm |
