| Applications: | Blue metal, Marble/Granite, Sand, Other construction material, Market load |
|---|---|
| Engine: | H Series 6ETI3UN turbocharged with inline FIP |
| Power: | 180 hp @ 2400 rpm |
| Torque: | 670 Nm @ 1300 - 1600 rpm |
| Clutch: | Single dry plate, booster CWG, 380mm Facing dia with 14.27 lining thik |
| Transmission: | ALGB940, FGR 9.01 |
| Suspension: | Semi elliptical laminated multileaf |
| Cabin: | Factory built G45 MKIII cowl- Sleeper version |
| Tyre: | 10.00 x 20 - 16 PR Nylon ply - (radial ply optional) |
| Max speed: | 78 kmph |
| Gradeability: | 21.06% |
| GVW: | 25000 kgs |
| Wheelbase: | 4902 mm |
| Loading span: | 23.5 ft |
